Features
3.5 inch IPS screen
2MP (1920×1080) real-time H.265 coding
Face recognition distance: 0.3m-2m
Support face detection technology distinguishing real faces from non-real face spoof attacks
Support 3D DNR, HWDR, BLC, HLC, Defog, etc.
Support multiple door opening modes (by swiping card, by password, by face recognition, etc.)
Support door opening by indoor station or by mobile APP
Support copy-prevention for IC card
Support anti-tampering alarm; support triggering alarms when the door is not secured or the door is broken by others
One-button calling indoor station
Support card reader access access via RS485 interface
Support 2.4G Wi-Fi; Support P2P function
Support remote surveillance via mobile APP, web browser or tablet PC
Intelligent analytics: video exception detection, face detection, face capture, face comparison
IP67
Access Control :-
Face picture, ID number, list type(group), name, gender, age, phone number, card ID, password, door opening mode, note
By face recognition/swiping card/password/indoor station/APP
Secondary Door Station
50000 event items can be recorded
| AES | Auto/Manual; Manual:1/2s ~ 1/100000s |
| Audio Inputs | G711A/U Built-in MIC×1, built-in speaker×1; support noise suppression and echo cancellation |
| BLC | Yes |
| BLC/SSDR (WDR) | 120dB |
| DNR | 2D/3D NR |
| Dimensions | Approx. 210mm × 104mm ×30mm |
| Image Quality | 1920×1080 |
| Image Sensor (CCD) | 1/2.8" Progressive Scan CMOS |
| Lens | M8 HD dual lens: 2.3mm@F2.2 |
| Minimum Illumination - Colour | Color：0.0085lux@F1.2，AGC ON |
| Minimum Illumination - Mono | B&W：0 lux with IR |
| POE | Yes |
| Power | DC12V/PoE |
| Power Consumption | < 12W |
| Resolution (Best) | 1080P(1920×1080), 720P(1280×720), D1, CIF, 480×240 |
| S/N Ratio | ≧50dB |
| Storage Media & Capacity | 1CH built-in micro SD card, up to 256GB |
| Within Range of IR LEDs | 0.3-2m |
