FV-PRO AH7524DI - NEW! ColourVision 2MP fixed Eyeball Dome with Dual Illumination & Built-in Audio - COMING SOON!
Please login for pricing
2MP 1080P real-time image, high resolution, true color
AHD / TVI / CVI lossless high-definition video output
CMOS progressive scan, perfectly capturing the moving object
Supports OSD menu
Supports DWDR
High speed, long distance and real time transmission
The LED can be automatically turned on at low illumination
20 ~ 30m LED view distance
20 ~ 30m White Light view distance
Support COC
Support coaxial audio transmission in TVI signal mode
IP67
| AES | Yes |
| AGC | Yes |
| Aperture Correction | H aperture V aperture |
| Audio Inputs | 1CH built-in MIC |
| BLC | Yes |
| BLC/SSDR (WDR) | Digital WDR |
| Connection Cable | BNC & DC |
| DNR | 3D |
| Dimensions | Ф 94.6 x 82.8 |
| Dual Streaming | Yes |
| Gamma Correction | 0.45 |
| Lens | 2.8mm |
| Power | 12VDC |
| Power Consumption | LED OFF : < 1.5 W; LED ON : < 3W |
| Power Source | 12V DC Regulated |
| Resolution (Best) | 2MP |
| S/N Ratio | ≥52dB ( AGC OFF ) |
| Scanning System | PAL |
| Shutter | 1/50s~1/50000s |
| Sync System | 2:1 Internal |
| Sync. Type | Internal |
| Video Output Signal | 1.0vp-p, 75 ohm composite |
| Video output | AHD / TVI /CVI |
| Within Range of IR LEDs | 20-30m IR and White Light |
