CL1990SHR - 700TVL Pro Sony True Day/Night Hi- Res 12/24v Camera

Please login for pricing or apply for an account

Availability: Reward Points:

KEY Features:

  • 700TVL Colour Resolution OSD Menu Control of all functions.
  • Lumii 3 Enhanced Settings.
  • DNR.
  • Backlight Processing.
  • WDR on/off.
  • High Lite Compensation.
  • 4 Zone Motion Detection.
  • 8 Zone Privacy Masks.
  • DC12V / AC24V Dual Voltage.
BLC/SSDR (WDR) ON / OFF
Dimensions 129(L) x 54(H) x 65(W)
Effective Pixel 976(H) X 582(V) PIXEL(PAL)
Gamma Correction 0.45 typ or 1 selectable
Horizontal Resolution 700+TVL Colour
Image Sensor (CCD) 1/3" SONY EXVIEW II HAD CCD IMAGE SENSOR
Minimum Illumination - Colour 0.02 Lux @ f1.2 Colour
Minimum Illumination - Mono 0.01 Lux @ f1.2 B/W
Power Consumption 5W
Power Source DC12V / AC24V Dual Voltage.
S/N Ratio 50 dB +
Scanning System PAL
Sync System 2:1 Interlace - V: 50Hz H: 15.625KHz
Sync. Type Internal / Line Lock Selectable (AC only)
Video output BNC Composite
Weight(Cameras) 500g

Reviews

Be the first to leave a review for this product.

Product

CL1990SHR - 700TVL Pro Sony True Day/Night Hi- Res 12/24v Camera

KEY Features:

  • 700TVL Colour Resolution OSD Menu Control of all functions.
  • Lumii 3 Enhanced Settings.
  • DNR.
  • Backlight Processing.
  • WDR on/off.
  • High Lite Compensation.
  • 4 Zone Motion Detection.
  • 8 Zone Privacy Masks.
  • DC12V / AC24V Dual Voltage.

Details

Professional Grade True Color Day / Night Camera with Auto Filter change for perfect daylight colour and enhanced night mono. This model uses the High Density Sony 1/3" Exview II HAD CCD and DSP Processing for 700TVL High Resolution Colour with DNR and Excellent low light sensitivity.

Additional Information

BLC/SSDR (WDR) ON / OFF
Dimensions 129(L) x 54(H) x 65(W)
Effective Pixel 976(H) X 582(V) PIXEL(PAL)
Gamma Correction 0.45 typ or 1 selectable
Horizontal Resolution 700+TVL Colour
Image Sensor (CCD) 1/3" SONY EXVIEW II HAD CCD IMAGE SENSOR
Minimum Illumination - Colour 0.02 Lux @ f1.2 Colour
Minimum Illumination - Mono 0.01 Lux @ f1.2 B/W
Power Consumption 5W
Power Source DC12V / AC24V Dual Voltage.
S/N Ratio 50 dB +
Scanning System PAL
Sync System 2:1 Interlace - V: 50Hz H: 15.625KHz
Sync. Type Internal / Line Lock Selectable (AC only)
Video output BNC Composite
Weight(Cameras) 500g
